Manufacturer:National Instruments

Model Number:PXI-7811R

Interface:PCI Express

Processor:Intel Atom E3826 1.33 GHz

Memory:2 GB DDR3L RAM

Storage:16 GB eMMC Flash Storage

Operating System:Windows Embedded Standard 7

Analog Input Channels:8 single-ended channels

Sampling Rate:Up to 1 MS/s per channel

Resolution:16-bit

Analog Output Channels:2 channels

Digital I/O Lines:40 lines

Field Programmable Gate Array (FPGA):Cyclone IV EP4CE115F29C7N

Power Supply:12V DC, 2A

    The National Instruments PXI-7811R Real-Time Controller provides exceptional performance and reliability for demanding real-time applications. It is equipped with an Intel Atom E3827 processor running at 1.33 GHz, ensuring fast data processing speeds and high accuracy.

    With 2 GB DDR3L RAM and 4 GB eMMC Flash storage, this module offers ample memory resources for storing and processing large amounts of data efficiently.

    It supports a variety of connectivity options including 1 Gigabit Ethernet, 4 USB 2.0 ports, 2 RS-232 ports, and 2 RS-485 ports, allowing seamless integration with other devices and systems.

    The PXI-7811R is compatible with 1 PXI Express slot and 2 PXI/PXIe hybrid slots, providing flexible expansion capabilities for adding additional modules as needed.

    Built to withstand harsh environments, this module operates over a wide temperature range from -20°C to +70°C, making it suitable for use in industrial settings where conditions can be extreme.
