IEMMU21 Full range of modules ABB PLC card controller
Brand ABB Color Standard Application Industrial height 368mm rated current 150mA
Protection Level IP45 Suitable for motor power 249KW Application Site Power Industry BOM Number GJR2391500R1220 Power industry HIEE401782R0001 Part Number IEMMU21
Applicable pipe 2 Whether imported is weighing 3.68 kg can be sold nationwide
IEMMU21 Full range of modules ABB PLC card controller
The ProLynx series of DC-DC converters accelerates time to market by reducing application design cycles that require wide input voltage tolerances. These energy-efficient, excellent thermal attenuation modules operate in an ultra-wide input range from 9 VIN to 36 VIN and are programmed with external resistors to provide a regulated output voltage range from 3.0 VDC to 18 VDC. The hardened (-D) version is capable of operating at temperatures up to 105°C and also withstands higher vibration and shock levels (MIL STD 810F).
Two features added to the family include reverse regulation of the voltage control loop based on the output voltage and adjustable current limits. Other features include remote on/off, adjustable output voltage, overcurrent and overtemperature protection, and synchronization capabilities. Tunable Loop? The function allows users to optimize the dynamic response of the converter to match the load to the smaller output capacitance, thereby saving cost and PWB area. AutoLimit enables the module to provide high output power over the entire voltage range. 9 V to 36 V ProLynx can also be used for negative output voltage loads in specific application modes.
ABB Embedded Power
12 A ProLynx non-isolated DC-DC power module
ABB Embedded Power offers 12 A ProLynx non-isolated DC-DC power modules with output voltages from 3 VDC to 18 VDC set via external resistors
ABB Embedded Power ProLynx Power Module Image ABB Embedded Power’s ProLynx series of DC-DC converters accelerates time to market by reducing application design cycles that require wide input voltage tolerances. These energy-efficient, excellent thermal attenuation modules operate in an ultra-wide input range from 9 VIN to 36 VIN and are programmed with external resistors to provide a regulated output voltage range from 3.0 VDC to 18 VDC. The hardened (-D) version is capable of operating at temperatures up to 105°C and also withstands higher vibration and shock levels (MIL STD 810F).
Two features added to the family include reverse regulation of the voltage control loop based on the output voltage and adjustable current limits. Other features include remote on/off, adjustable output voltage, overcurrent and overtemperature protection, and synchronization capabilities. Tunable Loop? The function allows users to optimize the dynamic response of the converter to match the load to the smaller output capacitance, thereby saving cost and PWB area. AutoLimit enables the module to provide high output power over the entire voltage range. 9 V to 36 V ProLynx can also be used for negative output voltage loads in specific application modes.
ABB Embedded Power ProLynx power module picture
peculiarity
Compliance with RoHS II EU Directive 2011/65/EC
Compatible with lead-free or SnPb reflow environments (Z version)
Compliance with IPC-9592 (September 2008) Class 2 Class II
Fast transient response adjustable control loop
Remote detection
Optional positive or negative logic remote on/off
Output overcurrent protection (non-locking)
Approved by UL 60950-1 2nd Edition, certified by CSA C22.2 60950-1-07, and licensed by VDE (EN60950-1 2nd Edition)
Monotonic starting
Synchronization capability
Small size and flat shape: large 33 mm x 13.46 mm x 10 mm (large 1.3 in x 0.53 in x 0.39 in)
The output voltage can be set from 3 VDC to 18 VDC via an external resistor
Wide operating temperature range (-40°C to 85°C)
