GE Fanuc-IC693MDL740 American General Electric analog output module
Brand ABB Color Standard Application Industrial height 360mm rated current 506mA
Protection Level IP45 Suitable for motor power 108KW Application Site Power Industry BOM Number GJR2391500R1220 Power industry HIEE401782R0001 Part Number ic693mdl740
Applicable pipe 2 Whether imported is weighing 5.69 kg can be sold nationwide
GE Fanuc-IC693MDL740 American General Electric analog output module
The GE Fanuc 90-30 Series IC693MDL740 is a 12/24 positive logic DC output module. The model has positive logic so that the module provides current from the positive power bus terminal or a common user to the required load. The output electronics are placed between the output module and the power bus.
The required voltage rating for the IC693MDL750 module is 12/24 volt DC with a maximum output current of 0.5 amps per point and 2 amps per common point.
The IC693MDL740 design has 16 common points divided into two equal groups. Each group has eight output points and a common output pin. The structure of the module has a hinged door in which a plug-in can be placed between the inner and outer surfaces. When the door is closed, the inner surface of the hinged door contains the wiring information of the circuit,
The outer surface has identification information about the circuit. The blue color on the left of the insert indicates that the IC63MDL740 module is a low-voltage module. The IC693MDL740 has an LED indicator to show the circuit status. The LED indicator consists of two rows of green LED lights, with the top row labeled A1 and the bottom row labeled B1.
The field equipment used by the module is operated by an external power supply. This can be installed into any input or output slot of a 90-30 programmable logic control system.
