Model Type:SLC 500

Model Number:1746-IM16

Manufacturer:Allen Bradley

Number of Channels:16

Input Voltage Range:10 – 30 VAC, 10 – 30 VDC (Sink)

Off-State Input Voltage:3 VAC/VDC

Nominal Current:8 MA at 24 VAC/VDC

Off-State Current:1 MA AC/DC

Isolation:Communication Circuits: 500 VDC, Backplane: 1500 VAC

Processor:SLC 500

Enclosure Type:Open Type

Mounting:Chassis

Temperature Rating:0 – 60 DEG C

Environmental Conditions:5 – 95% Non-Condensing Relative Humidity

Shock Resistance:30 G

    Unleash the power of Allen Bradley’s 1746-IM16 Digital AC Input Module for your industrial automation endeavors. This module is designed to enhance system performance and reliability by providing precise and efficient signal acquisition.

    With its capacity for 16 channels, this module ensures a comprehensive coverage of your monitoring requirements. Its versatility in handling both AC and DC signals makes it adaptable to a wide range of applications within your facility.

    Featuring exceptional isolation levels between communication circuits, backplane, and processor, the 1746-IM16 safeguards against interference, ensuring stable operation even under demanding conditions.

    The module is meticulously engineered to withstand temperature fluctuations from 0 to 60 degrees Celsius, ensuring reliable function across various operational environments. It’s also designed to operate effectively in humid conditions, thanks to its non-condensing relative humidity tolerance.

    Compliant with international safety standards such as GOST_R, KCC, and more, this Allen Bradley module guarantees adherence to global industrial norms, making it a secure choice for integration into any global network.
