ABB inverter DSQC346B servo drive unit
Brand ABB color standard Application Industrial height 236mm rated current 188mA
Protection Level IP45 Suitable for motor power 235KW Application Site Power Industry Material Code GJR2391500R1220 Power industry HIEE401782R0001 Part Number DSQC346B
Applicable pipe 2 Whether imported is weighing 4.88 kg can be sold nationwide
ABB inverter DSQC346B servo drive unit
To update the OS, perform the following steps according to your touchscreen model: 1. Power on the HMI, connect the hardware, and set the download path on the control panel. 2. Select the menu command “Project ▶ Transfer ▶ Communication Settings” from WinCCflexible of the configuration computer. This will open the Communication Settings dialog box. 3. Select an HMI device type. 4. Set connection parameters. 5. Click OK to close the dialog box. 6. Select the menu command “Project ▶ Transfer ▶ Update operating system” from WinCCflexible. 7. In Image Path, select the folder that contains the HMI device image file *.img. HMI device image files can be found under “WinCCflexibleImages” in the WinCCflexible installation folder, or on the appropriate WinCCflexible installation CD. 8. Select Open. When the image file is opened, the version information of the HMI device image file is displayed in the output area. 9. Select Update OS from WinCCflexible to run the operating system update. Follow the instructions for WinCCflexible. A status view appears indicating the update progress of the operating system.
Note: the OS update time is relatively long, the system will automatically restart after the update, and then the restart can not be powered off before the completion, otherwise it can only be taken to repair. After updating the system will automatically restart, it is recommended to use Ethernet update, can be much faster.
ABB inverter DSQC346B servo drive unit
