ABB distributed control system SC513 programmable logic controller
Brand ABB Color Standard Application Industrial height 125mm rated current 430mA
Protection Level IP45 Suitable for motor power 576KW Application Site Power Industry Material Code GJR2391500R1220 Power industry HIEE401782R0001 Part No. SC513
Applicable pipe 2 Whether imported is weighing 4.38 kg can be sold nationwide
ABB distributed control system SC513 programmable logic controller
SC513 Controller Features:
⊙ It is based on the ARM@Cortex TM-M3 kernel and a Harvard bus structure
⊙DMA controller, single cycle multiplication instruction, hardware division instruction
⊙ Compared with ARM7TDMI, the running speed can be 35% faster and the code can be 45% less
⊙90DMIPs running speed, 72MHZ main frequency running CPU
⊙6K 20K bytes of SRAM, 32K 128K bytes of FLASH
⊙2 16-channel 12-bit analog-to-digital converters, 1US conversion time
⊙ High-speed communication port: USB, USATR, CAN, SPI, I2C
⊙ Low power mode with wake function, internal RC shaker, built-in reset circuit
In the standby mode, the typical power consumption value is only 2UA, which is very suitable for battery powered applications
⊙2.0V 3.6V Operating voltage (5V I/O voltage tolerance)
⊙ Package: 48LQFP 144L1FP, operating temperature scale: -40℃ + 85℃ ~105℃
⊙3 16-bit universal timers, PWM output, dead zone alignment, edge/center alignment waveform and emergency braking,
1 system time timer: 24-bit self-decreasing type
Pioneering peripherals:
USB 2.0 12 Mbit/s high speed SPI 18 Mbit/s, master and slave form GPIO
The flipping frequency is 18MHZ
USART 4.5MB/s high speed I2C 40KHZ
PWM timer 72MHZ clock input
