Product Details : 5501-381 WOODWARD Digital Control Series Redundant (TMR) Power Board

Product description
Panels 5501-381 are manufactured by Woodward and are part of the MicroNet family of digital controls.The board is another major two-mode multimode(TMR)power board that uses 220 volts AC.The board has the specifications required to operate the module without any errors or failures,one of which is a maximum input power of 1250 VA.The board also has A specific input circuit breaker/power fuse disconnect which,unlike other TMR power boards,will have a 10 A time delay.
The location of the 5501-381 board will be in the MicroNet TMR main control power supply case,which can accommodate up to two TMR power supply boards,but when used together they must be located in a two-person separate case but connected by a ribbon cable.One of the main features of the board is that it can be replaced with power,which means that the control case does not have to stop operating when the 5501-381 board is removed.
On the front panel of the 5501-381 board,there are four indicators,the four indicators are respectively input power failure,overheating and normal indicators,the only green indicator on the board is OK LED,the indicator light indicates that the power is running as required,without any error or failure
For all information about the 5501-381 board,refer to the 26166V2 manual that describes the board or the 26167V1 manual that provides more in-depth information about the board’s features.
