64711245C programmable logic controller module

The 64711245C is a programmable logic controller (PLC) module.
Interface and communication: 64711245C The product has a number of electrical interfaces, including six RJ45 electrical interfaces, support 10Base-T/100Base-TX adaptive, and full duplex/half duplex adaptive or forced mode of operation.

In terms of optical interface, it supports 2 100Base-FX optical interfaces, supports redundant ring network, and optional SC/ST/FC interface, supports single mode and multi-mode fiber.
In terms of communication interface, it is a substitute for CS513 and MasterBus 300, with its own microprocessor (CPU) to reduce the load of the main CPU.
Network and Configuration: 64711245C uses fiber optic cable in the link segment, the maximum distance between two stations can extend up to 3,500 meters (11,480 feet). Fiber optic link segments up to 1 km (3,280 ft).
By using an active star coupler, the maximum distance between the two sites can be further increased to 4,500 meters (14,760 feet).
It has a maximum RCOM/RCOM+ transfer speed of 19,200 bits per second.

Power supply and protection: The power supply is designed for 24VDC power supply redundancy input (12VDC ~ 36VDC), and built-in overload protection and reverse protection.
The product provides 1000V electromagnetic isolation protection.
64711245C  Mechanical and working environment: Size (H W D) is 136mm52mm105mm, using IP30 level protection corrugated high-strength metal housing.
In terms of working environment, the operating temperature range is 0 ° C to 70 ° C, the extended operating temperature range is -40 ° C to 85 ° C, the storage temperature range is -45 ° C to 85 ° C, and the humidity range is 5% to 95% (no condensation).
